Calibre Physical Verification

The Calibre Physical Verification nmPlatform provides foundries, IDMs, and fabless companies with a comprehensive and innovative suite of functionality that addresses their physical verification needs from established nodes to the most advanced processes.

Calibre Confidence

Calibre Physical Verification

The Calibre nmDRC tool has long led the industry, but today’s designs also demand novel technologies that enable design companies to accelerate time to market and achieve faster innovation. From equation-based DRC to multi-patterning, machine learning, and EDA in the cloud, the Calibre toolsuite provides the proven performance, technology, accuracy, and capacity to handle any design, at any node, at any foundry.

EDA digital twin CPU

Calibre Physical Verification Products

Calibre physical verification is the industry leader for accuracy, reliability, and performance. The Calibre nmPlatform provides a comprehensive and innovative suite of functionality that enables foundries, IDMs, and fabless companies to efficiently address all physical verification requirements.

aerial view of integrated circuit | The Calibre nmDRC platform enables reduced cycle time with revolutionary new capabilities that substantially differentiate Calibre nmDRC design rule checking from traditional DRC tools.
Industry-Leading DRC
all

Calibre nmDRC

The Calibre nmDRC platform enables reduced cycle time with revolutionary new capabilities that substantially differentiate Calibre nmDRC design rule checking from traditional DRC tools.

integrated circuit floating with signals flying into the air | The Calibre nmDRC Recon technology lets design teams perform physical verification of full-chip design layouts during early stages in the design cycle, while different components are still immature.
Design stage DRC verification
all

Calibre nmDRC Recon

The Calibre nmDRC Recon technology lets design teams perform physical verification of full-chip design layouts during early stages in the design cycle, while different components are still immature or the full chip is incomplete.

columns of binary code | The Calibre Pattern Matching tool works within the Calibre nmPlatform to enable powerful, integrated pattern-based design verification and manufacturing flows.
Enables Complex Checking
all

Calibre Pattern Matching

The Calibre Pattern Matching tool works within the Calibre nmPlatform to enable powerful, integrated pattern-based design verification and manufacturing flows.

IC layout screenshot | Calibre Multi-Patterning technology provides industry-leading multi-patterning decomposition, verification, and error debugging. Supports all major foundry methodologies and processes.
Comprehensive MP Technology
all

Calibre Multi-Patterning

Calibre Multi-Patterning technology provides industry-leading multi-patterning decomposition, verification, and error debugging. Supports all major foundry methodologies and processes.

Rendering showing a 3d stack.
Extends Calibre verification
all

Calibre 3DSTACK

Calibre 3DSTACK technology provides comprehensive support for an extensive range of multi-die integration methodologies and processes, including system-level DRC, layout versus schematic (LVS) and parasitic extraction (PEX).

An image showing, from left to right: an image of a chip-package, then drilling down to the chiplet level, and then to the transistor metal stack level.
Accurate thermal analysis
all

Calibre 3DThermal

Calibre 3DThermal performs highly accurate and computationally efficient thermal analysis throughout the IC design flow.

IC with connections carrying signals | Calibre Auto-Waivers technology lets users waive false physical and circuit verification violations to focus on real errors, speed design process, make debug more efficient, and shorten schedules.
Automated Waiver Management
all

Calibre Auto-Waivers

Calibre Auto-Waivers technology lets users waive false physical and circuit verification violations to focus on real errors, speed design process, make debug more efficient, and shorten schedules.

WEBINAR

Calibre in the Cloud

Node over node computational growth, security enhancements, and improved ease of use make 3rd party clouds attractive for surge compute applications like Calibre nmDRC verification. Find out more in this on-demand webinar.

Hand touching glowing blue dial | Calibre Design Solutions delivers a complete IC verification and DFM optimization EDA platform that speeds designs from creation to manufacturing, addressing all sign-off requirements.
