Calibre Vision AI

Calibre Vision AI is an advanced DRC debug solution that transforms how teams analyze and resolve design violations. It combines ultra-fast processing of massive violation databases with powerful full-chip visualization through an intelligent violation density heatmap. The platform's AI/ML-powered error clustering groups related violations into distinct classification types (called “Signals”), enabling efficient triage and systematic root cause analysis.

Its hierarchical debug capabilities allow precise violation isolation by design block, streamlining collaboration between chip and block-level teams. The solution integrates seamlessly with popular layout viewers and place-and-route tools, while supporting traditional debug workflows through ASCII RDB export and HTML reporting features. This comprehensive integration ensures consistent data across all tools and enables teams to fix violations directly in their preferred design environment.

It dramatically reduces the time and effort required to identify and fix critical design issues during chip integration. Through intelligent violation clustering and full-chip visualization, engineers can quickly identify critical hotspots and systematic issues across the entire design, rather than getting lost in individual violations. Calibre Vision AI enables efficient collaboration between chip integration and block teams in several ways:

• Automatic clustering of related violations helps prioritize debug efforts
• Hierarchical debug capabilities allow precise isolation of issues by design block
• Shareable bookmarks and analysis states maintain debug context across teams
• Direct integration with layout viewers and place-and-route tools enables fixes in familiar environments
• Support for ASCII RDB export ensures compatibility with traditional debug workflows

This comprehensive approach means teams can focus on resolving high-priority issues while maintaining productivity within their established design flows

Calibre Vision AI is designed for semiconductor design teams working at the forefront of advanced technology nodes. It is particularly valuable for SoC and chip integration teams managing complex multi-block designs, physical design engineers handling massive volumes of DRC violations and layout engineers working on advanced-node designs.

Organizations that will benefit most include companies developing large-scale integrated circuits with multiple IP blocks, especially those already leveraging the Calibre ecosystem for physical verification. The tool is particularly impactful for semiconductor firms pushing the boundaries of advanced technology nodes and design houses facing increasing time-to-market pressures.

Key indicators that your organization would benefit from Calibre Vision AI include:

• Extended debug cycles due to growing design complexity
• Challenges in managing cross-team collaboration during integration
• Difficulties in identifying systematic violation patterns across full-chip designs
• The need to reduce chip integration cycle times while maintaining quality

While particularly powerful for advanced-node designs, Calibre Vision AI's efficiency benefits extend to any team dealing with complex physical verification challenges and seeking to streamline their debug processes. It offers significant value to organizations looking to modernize their traditional DRC debug methodologies and accelerate their overall chip development cycle.

Yes, it fully supports and enhances the Graybox DRC workflow. The tool can efficiently process complete chip-level DRC results, including grayboxed blocks, which is particularly valuable when certain blocks aren't ready for full DRC verification but are already included in the SoC. This capability allows design teams to maintain design progress while managing incomplete blocks. Additionally, the development team is actively working on validating the DRC IP waiver flow to further streamline this process, with future development plans including support for Antenna, Density, and HV-DRC debug capabilities.

Yes, Calibre Vision AI provides seamless integration with external design environments. The tool can highlight design violations directly in layout viewers and place-and-route tools, allowing engineers to quickly identify and fix issues within their preferred design environment. This capability is enhanced by the ability to export ASCII RDBs for specific blocks, enabling traditional debug workflows while maintaining consistent data across all tools.

Calibre Vision AI employs sophisticated artificial intelligence and machine learning algorithms to revolutionize DRC debug analysis. At its core, the AI technology powers the innovative “Signals” feature, which automatically identifies and clusters related DRC violations that share common characteristics or root causes.

The AI engine automatically categorizes these Signals into seven distinct classification types, enabling engineers to:

• Quickly identify systematic violation patterns
• Prioritize debug efforts based on violation similarities
• Address multiple related violations simultaneously
• Reduce time spent on repetitive debugging tasks

A key advantage of Calibre Vision AI's machine learning implementation is its technology-agnostic nature. The system works automatically out of the box, requiring no setup, training datasets or specialized configuration. This means teams can immediately benefit from AI-powered analysis without investing time in system training or maintenance.

Calibre Vision AI is deeply integrated within the broader Calibre ecosystem. It works seamlessly with Calibre nmDRC for generating OASIS results required for Signal generation and chip-level debug. The tool also integrates with Calibre Auto-Waivers, Calibre DESIGNrev, and Calibre RVE for a comprehensive design and verification flow. This integration strategy is part of Siemens EDA's broader initiative to incorporate AI/ML capabilities across their tool suite, aimed at reducing cycle times and improving overall design efficiency.  Visit our Calibre Intelligence page for a deeper dive.
